The model number HES3D-E160 refers to a popular concealed, 3-way adjustable door hinge manufactured by Sugatsune (LAMP). It is part of the extensive HES3D series, known for creating seamless, flush-mount doors that completely hide the hinge mechanism The “E” in the model name indicates that it is an “Easy-Installation” model with a relatively shallow mortise, and “160” refers to its 160 mm length. It is a workhorse model for standard to medium-heavy interior doors
| Item Code | Item Name | Colour |
| 170-041-454 | HES3D-E160DC | Silver |
| 170-041-455 | HES3D-E160DN | Champagne Gold |
| 170-041-456 | HES3D-E160BL | Black |
| Door Width | Door Height | Door Thickness | Opening Angle | Load Capacity (2 pcs) | Load Capacity (3 pcs) |
| Max. 900 mm | Max. 2400 mm | Min. 36 mm | 180° | 55 kg | 70 kg |
