Description

GS-GL5 GLASS DOOR CAM LOCK (MILLION LOCK SERIES)

PRODUCT INFORMATION

Features

• Cylinder lock for glass swing door.
• Can be used together with glass hinge GS-GH5 and bracket GS-GB5 for a total design of your showcase.
• Dimple key with up to 1 million key changes. Reversible key.
• Turn the key 90° to lock and unlock. Key can only be removed when locked.

Remarks

• The direction of lock plate is fixed.
• File on glass door is recommended for safe usage.

Parts supplied with set

• Countersunk head wood screw 2.7 × 13
• Key
• Strike plate

INSTSLLSTION DRAWING

Installed with glass hinge GS-GH5 and Glass bracket GSGB5 Glass top panel (Used with Bracket GS-GB5)

APPLICABLE DOOR
