The HETTICH Actro 5D L is not just a runner; it’s the hidden powerhouse behind truly exceptional drawers. Its robust design guarantees exceptional stability, ensuring even large, heavily loaded drawers maintain perfect alignment and never sag. The secret lies in its advanced engineering, delivering an unequalled running action that is both incredibly smooth and whisper-quiet. With the integrated Silent System (soft-close), drawers glide to a gentle, controlled close, transforming every interaction into a moment of refined luxury. For contemporary, handle-less designs, the optional “Push to Open Silent” feature offers effortless access with just a light press.
Advice:
| Load class | L (40 kg) |
| Nominal length | 450 mm |
| Mounting side | left and right |
| User friendly features | Silent System compatible with Push to open Silent |
| Drawer length SKL | 440 mm |
| Load capacity kg | 40 kg |
| Hole spacing b1 | 256 mm |
| Type of runner | Concealed runner |
| Type of drawer runner | Full extension runner |
| Minimum cabinet body depth KT | 453 mm |
| Type of installation | slide on installation |
| Installed width (side profile thickness) | EB 21 (drawer side profile thickness ≤ 16mm) |
| Components | Drawer runners |
| EAN | 4023149327018 |
| Previous order no. | 9257093 |
| Order no. | 9318286 |
| PU | 1 ea. |
| Mounting side | left and right |
| Components | Accessories |
| Colour | anthracite |
| EAN | 4023149335235 |
| Previous order no. | 9257268 |
| Order no. | 9320333 |
| PU | 5 ea. |
| Length | 2,000 mm |
| EAN | 4023149089336 |
| Order no. | 9236718 |
| PU | 100 ea. |
| System / drawer side profile height | 78 94 126 186/ 94 186/126 218/ 94 218/126 250/ 94 250/126 282/ 94 282/126 |
| User friendly features | Push to open Silent |
| Material | aluminium |
| Components | Accessories |
| Application | Actro 5D Actro Actro YOU Quadro 25 Quadro 4D V6 Quadro V6 Quadro V6+ Quadro V6 YOU Wooden drawer / Quadro V6 5D Wooden drawer / Quadro V6 YOU Wooden drawer / Quadro 25 2D Wooden drawer / Quadro 25 YOU |
| EAN | 4023149064234 |
| Order no. | 9221295 |
| PU | 20 ea. |
| System / drawer side profile height | 78 94 126 186/ 94 186/126 218/ 94 218/126 250/ 94 250/126 282/ 94 282/126 |
| User friendly features | Push to open Silent |
| Material | plastic |
| Components | Accessories |
| Application | Actro 5D Actro Actro YOU Quadro 25 Quadro 4D V6 Quadro V6 Quadro V6+ Quadro V6 YOU Wooden drawer / Quadro V6 5D Wooden drawer / Quadro V6 YOU Wooden drawer / Quadro 25 2D Wooden drawer / Quadro 25 YOU |
| Colour | grey |
